Product specifications:

Display Panel Details	Display Panel Brand	LG,Samsung,AUO,Chimei,etc... original brand new and grade A+
Display Panel Details		Size	23.6 inch
Customize Frame Color	Black, white, green, pink, ivory, wine red, blue, violet, ......can be customized
Body Material	Durable aluminum alloy frame + tempered glass to protect LCD panel against external impacts. front panel compliant NEMA / IP65 waterproof and dustproof standard,so that it can adapt to the harsh industrial site work environment, the most suitable for factory automation, machinery manufacturing, CNC equipment, textile equipment, communication networks, power automation and other industrial applications.
Display Screen Parameters	Display Ratio	16:9
		Contrast Ratio	1000:1
		Brightness	350 cd/m2 (upto 3500 cd/m2 high brightness as options)
		Colour	16.7M
		Resolution	1920*1080
		Viewing Angle	178/178
PC Configuration	CPU	CPU Rockchip 3566 Quad Core
		Chipset Frequency	2.0Ghz
		GPU	Mali-G52-2EE
		Ram and Flash	4GB DDR3 SDRAM and NAND FLASH: 32GB
		WiFi	802.11n Wifi Integated
Operation System	Android, Win7 , Win8, Win10, Ubuntu, VXWORKS, QNX, Linux etc...
Touch Screen	Touch Screen Type	Capacitive;Resistive(4-wire/5-wire); SAW/IR as options
		Touch Screen Interface	Serial (RS232) or USB or COM as options
		Surface Hardness	6H
Power Supply	Standby	≤3W
Power Supply		Working	≦15W
Environmental	Operating Temperature	-10 ~ 60°C
		Storage Temperature	-20 ~ 70°C
		Relative Humidity	5%~95% (Non condensation)
		Shake: SSD applied	1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

		Shock: SSD applied	10 G, IEC 60068-2-64, Half-sine wave, 11ms duration
		Waterproof	Front panel IP65

Features:

1.Versatile Installation Options: This all-in-one PC allows for flexible installation methods, including embedding it directly into surfaces,

hanging it on walls, or placing it on desktops, providing users with multiple placement options to suit their specific needs and space constraints.

2.IP65 Protection Rating: Equipped with an IP65 rating, this industrial monitor ensures protection against dust ingress and low-pressure water jets,

making it ideal for use in harsh environments or areas prone to dust and moisture, such as factories, warehouses, and outdoor installations.

3.Robust Sheet Metal Frame: The durable sheet metal shell not only provides a sleek appearance but also contributes to its

resistance to impacts and corrosion, ensuring long-term reliability and stability even in challenging conditions.

4.Capacitive Touchscreen Technology: The touchscreen monitor utilizes capacitive technology, which enables smooth and responsive operation

with high sensitivity and accuracy, allowing for seamless interaction and multitouch capabilities, enhancing user experience and productivity.

5.Wide Range of Applications: This industrial-grade computer is well-suited for a variety of industries, including manufacturing, automation,

transportation, and more. Its robust design and advanced features make it perfect for control systems, data acquisition, process monitoring,

and human-machine interface (HMI) solutions.

For more order quantity more discount more shipping options, OEM/ODM service,

Pls directly contact with us for more offers and details. Thank you very much!

Tag:

Place of Origin:	Guangdong, China
Brand Name:	Shine Star/OEM
Certification:	CE-LVD, CE-EMC, FCC, ROHS, ISO9001
Model Number:	SY236C

Minimum Order Quantity:	1 unit
Price:	To be negotiated
Packaging Details:	Depend on the final design you choose
Delivery Time:	15 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000 units per month

Metal Housing+Tempered Glass:	Aluminum Alloy Frame+tempered Glass	Touch Screen Type:	Capacitive Touch,Multi-points, 10-points
Full HD 1080P:	Support	Brightness:	350 Cd/m2 (upto 3500 Cd/m2 High Brightness As Options)
Built-in Camera:	Option	OS:	Android, Windows, Ubuntu, Linux As Options
Input Voltage:	12V 24V As Options	Ports:	USB, HDMI, Ethernet
