Place of Origin: | Guangdong, China |
---|---|
Brand Name: | Shine Star/OEM |
Certification: | CE-LVD, CE-EMC, FCC, ROHS, ISO9001 |
Model Number: | SY104C |
Minimum Order Quantity: | 1 unit |
Price: | To be negotiated |
Packaging Details: | Depend on the final design you choose |
Delivery Time: | 15 work days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 1000 units per month |
Type: | TFT LCD LED | Resolution: | 800*600 |
---|---|---|---|
Network Function: | Wired LAN RJ45,Wireless WIFI,3G, 4G Network | Touch Screen Type: | Capacitive Touch,Multi-points, 10-points |
Built-in Speakers: | Yes | Brightness: | 400 Cd/m2 (upto 3500 Cd/m2 High Brightness As Options) |
Input Voltage: | 12V 24V As Options | Port: | All China Ports |
Display Panel Details
|
Display Panel Brand
|
LG,Samsung,AUO,Chimei,etc... original brand new and grade A+
|
|
|
Size
|
10.4 inch
|
|
Customize Frame Color
|
Black, white, green, pink, ivory, wine red, blue, violet, ......can be customized
|
|
|
Body Material
|
Durable aluminum alloy frame + tempered glass to protect LCD panel against external impacts. front panel compliant NEMA / IP65 waterproof and dustproof standard,so that it can adapt to the harsh industrial site work environment, the most suitable for factory automation, machinery manufacturing, CNC equipment, textile equipment, communication networks, power automation and other industrial applications.
|
|
|
PC Configuration
|
CPU
|
Intel® J1900 quad core (1.99GHz)
|
|
|
RAM
|
DDR III / 4GB
|
|
|
SSD
|
128GB
|
|
|
Chipset
|
Intel Bay trail SOC
|
|
|
Audio
|
Realtek ALC662 HD, support Line-out, MIC-in ports
|
|
|
WiFi
|
802.11n Wifi Integated
|
|
Display Screen Parameters
|
Display Ratio
|
4:3
|
|
|
Contrast Ratio
|
500:1
|
|
|
Resolution
|
800*600
|
|
|
Brightness
|
400cd/m2 (upto 3500cd/m2 high brightness as options)
|
|
|
Colour
|
16.7M
|
|
Touch Screen
|
Touch Screen Type
|
Resistive(4-wire/5-wire); capacitive; SAW/IR as options
|
|
|
Touch Screen Interface
|
Serial (RS232) or USB or COM as options
|
|
|
Surface Hardness
|
6H
|
|
Power Supply
|
Standby
|
≤3W
|
|
|
Output Rating
|
≦15W
|
|
Environmental
|
Operating Temperature
|
-10 ~ 60°C
|
|
|
Storage Temperature
|
-20 ~ 70°C
|
|
|
Operating Humidity
|
5%~95% (Non condensation)
|
|
|
Storage Humidity
|
5%~95% (Non condensation)
|
|
|
|||
|
EMC
|
CE/FCC Class A
|
|
|
Water-proof
|
Front panel IP65
|
