Fanless 27 Inch IP65 Waterproof Touch Screen Industrial Panel PC With Fully Sealed

Basic Information
Place of Origin: Guangdong, China
Brand Name: Shine Star/OEM
Certification: CE-LVD, CE-EMC, FCC, ROHS, ISO9001
Model Number: SY270R
Minimum Order Quantity: 1 unit
Price: To be negotiated
Packaging Details: Depend on the final design you choose
Delivery Time: 15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 units per month
Material: Aluminum Alloy Frame+tempered Glass Type: Panel PC
Colur: 16.7M Resolution: 1920*1080
Built-in Camera: Option OS: Android, Windows, Ubuntu, Linux As Options
Input Voltage: 12V 24V As Options Port: All China Ports

Product Description



Fanless 27 Inch IP65 Waterproof Touch Screen Industrial Panel PC With Fully Sealed

Product specifications:

Display Panel Details
Display Panel Brand
LG,Samsung,AUO,Chimei,etc... original brand new and grade A+
Size
27 inch
Customize Frame Color
Black, white, green, pink, ivory, wine red, blue, violet, ......can be customized
Body Material
Durable aluminum alloy frame + tempered glass to protect LCD panel against external impacts. front panel compliant NEMA / IP65 waterproof and dustproof standard,so that it can adapt to the harsh industrial site work environment, the most suitable for factory automation, machinery manufacturing, CNC equipment, textile equipment, communication networks, power automation and other industrial applications.
PC Configuration
CPU
Intel® J1900 quad core (1.99GHz)
RAM
DDR III / 4GB
HDD
128GB SSD
Chipset
Intel Bay trail SOC
OS
Android OS, Windows OS, Linux OS as options
WiFi
802.11n Wifi Integated
Display Screen Paramters
Display Ratio
16:9
Contrast Ratio
2000:1
Brightness
350 cd/m2 (upto 3500 cd/m2 high brightness as options)
Resolution
1920*1080
Viewing Angle
178/178
Touch Screen
Touch Screen Type
Resistive(4-wire/5-wire); capacitive; SAW/IR as options
Touch Screen Interface
Serial (RS232) or USB or COM as options
Surface Hardness
6H
Power Supply
Standby
≤3W
Working
≦15W
Environmental
Operating Temperature
-10 ~ 60°C
Storage Temperature
-20 ~ 70°C
Relative humidity
5~95% (Non condensation)
Shake: SSD applied
1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
Shock: SSD applied
10 G, IEC 60068-2-64, Half-sine wave, 11ms duration
Waterproof
Front panel IP65



Features:
1.Versatile Installation Options: This all-in-one PC allows for flexible installation methods, including embedding it directly into surfaces,
hanging it on walls, or placing it on desktops, providing users with multiple placement options to suit their specific needs and space constraints.
2.IP65 Protection Rating: Equipped with an IP65 rating, this industrial monitor ensures protection against dust ingress and low-pressure water jets,
making it ideal for use in harsh environments or areas prone to dust and moisture, such as factories, warehouses, and outdoor installations.
3.Robust Aluminum Alloy Frame: The durable aluminum alloy frame not only provides a sleek appearance but also contributes to its
resistance to impacts and corrosion, ensuring long-term reliability and stability even in challenging conditions.
4.Resistive Touchscreen Technology: The touchscreen monitor employs resistive technology, offering accurate and reliable input recognition,
even when used with gloves or styluses, making it ideal for applications requiring precision and ease of use, such as industrial control systems,
data entry, and point-of-sale terminals.
5.Wide Range of Applications: This industrial-grade computer is well-suited for a variety of industries, including manufacturing, automation,
transportation, and more. Its robust design and advanced features make it perfect for control systems, data acquisition, process monitoring,
and human-machine interface (HMI) solutions.
