Name: Wide Working Temperature Waterproof Industrial All In One 15 Inch Panel PC Touch Screen
Brand: Shenzhen Wang Xin Yuan Electronic Technology Co., Ltd.
SKU: SY150C
Price: 425.00 USD
Availability: InStock

Wide Working Temperature Waterproof Industrial All In One 15 Inch Panel PC Touch Screen

Basic Information

Place of Origin:	Guangdong, China
Brand Name:	Shine Star/OEM
Certification:	CE-LVD, CE-EMC, FCC, ROHS, ISO9001
Model Number:	SY150C

Minimum Order Quantity:	1 unit
Price:	To be negotiated
Packaging Details:	Depend on the final design you choose
Delivery Time:	15 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000 units per month

Contact Now

Colour:

16.7M

Type:

Panel PC

Logo:

OEM/Customized

Material:

Aluminum Alloy Frame+tempered Glass

Resolution:

1024*768

Built-in Spaekers:

Yes

Input Voltage:

12V 24V As Options

Ports:

USB, HDMI, Ethernet

Product Description

Wide Temperature Range Waterproof Industrial All In One 15 Inch Panel PC Touch Screen

Product specifications:

Display Panel Details	Display Panel Brand	LG,Samsung,AUO,Chimei,etc... original brand new and grade A+
Display Panel Details		Size	15 inch
Customize Frame Color	Black, white, green, pink, ivory, wine red, blue, violet, ......can be customized
Body Material	Durable aluminum alloy frame + tempered glass to protect LCD panel against external impacts. front panel compliant NEMA / IP65 waterproof and dustproof standard,so that it can adapt to the harsh industrial site work environment, the most suitable for factory automation, machinery manufacturing, CNC equipment, textile equipment, communication networks, power automation and other industrial applications.
PC Configuration	CPU	CPU Rockchip 3566 Quad Core
		Chipset Frequency	2.0 Ghz
		GPU	Mali-G52-2EE
		Ram and Flash	4GB DDR3 SDRAM and NAND FLASH: 32GB
		WIFI	802.11n Wifi Integated
		OS	Android OS, Windows OS, Linux OS
Display Screen Parameters	Display Ratio	4:3
		Contrast Ratio	500:1
		Brightness	300 cd/m2 (upto 3500 cd/m2 high brightness as options)
		Colour	16.7M
		Viewing Angle	85/85/85/85
Touch Screen	Touch Screen Type	Resistive(4-wire/5-wire); Capacitive; SAW/IR as options
		TouchScreen Interface	Serial (RS232) or USB or COM as options
		Surface Hardness	6H
Power Supply	Standby	≤3W
Power Supply		Working	≦15W
Environmental	Operating Temperature	-20 ~ 70°C
		Storage Temperature	-30 ~ 80°C
		Relative Humidity	5~95% (Non condensation)
		Shake: SSD Applied	1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

		Shock: SSD Applied	10 G, IEC 60068-2-64, Half-sine wave, 11ms duration
		Water-proof	Front panel IP65

Features:

Our industrial panel pc are fully-integrated‚ waterproof and dustproof that combine high-performance different touch screen technologies in

industrial-grade TFT-LCD flat panels, with sleek, IP65 / NEMA 4-4 x Ingress rating flat front surface industrial design.
Our industrial pc provide reliability, durability, and long expected product life. Impervious to environmental conditions such as liquid spills, splashes

and wash-downs, these screens are the most contamination-resistant units available in the market. Our industrial IP65/ NEMA 4 touch computer

are designed for process control, food processing equipment, machine control, human interface, automation equipment and in-vehicle use applications.

For more order quantity more discount more shipping options, OEM/ODM service,

Pls directly contact with us for more offers and details. Thank you very much!
