All In One Wide Screen 10.1 Inch IP65 Industrial PC 10 Points Resisitive Touch Screen

Basic Information
Place of Origin: Guangdong, China
Brand Name: Shine Star/OEM
Certification: CE-LVD, CE-EMC, FCC, ROHS, ISO9001
Model Number: SY101R
Minimum Order Quantity: 1 unit
Price: To be negotiated
Packaging Details: Depend on the final design you choose
Delivery Time: 15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 units per month
Type: Panel PC Logo: OEM/Customized
Material: Sheet Metal Frame+tempered Glass Resolution: 1280*800
Color: Black, White, Silver Etc... Viewing Angle: 178/178
Lifespan: 100000h Port: All Of China Ports

Product Description



All In One Wide Screen 10.1 Inch IP65 Industrial PC 10 Points Resistive Touch Screen

Display Panel Details
   Display Panel Brand
   LG,Samsung,AUO,Chimei,etc... original brand             new and grade A+

   Size
   10.1 inch

Customize Frame Color
   Black, white, green, pink, ivory, wine red, blue, violet, ......can be customized
Body Material
   Sheet metal frame+tempered glass to protect the LCD panel from external impacts. The         front panel meets NEMA/IP65 waterproof and dustproof standards, making it suitable for         harsh industrial working environments and most suitable for industrial applications such as     factory automation, mechanical manufacturing, CNC equipment, textile equipment,                 communication networks, and power automation.

PC Configuration
   CPU
   Intel® J1900 quad core (1.99GHz)

   RAM
   DDR III / 4GB

   HDD
   128GB SSD

   Chipset
   Intel Bay trail SOC

   OS
   Android OS, Windows OS, Linux OS

   WiFi
   802.11n Wifi Integated

Display Screen Parameters
   Display Ratio
   16:10

   Contrast Ratio
   900:1

   Brightness
   300 cd/m2 (upto 3500 cd/m2 high brightness as           options)

   Colour
   16.7M 53% NTSC

   Resolution
   1280*800

Touch Screen
   Touch Screen Type
   Resisitive 10 points

   Touch Screen                                         Interface
   Serial (RS232) or USB or COM as options

   Surface Hardness
   6H

Power Supply
   Input Voltage
   DC12V or 24V

   Output Rating
   ≦20W

Environmental
   Operating Temperature
   -10 ℃~ 60°C

   Storage Temperature
   -20 ℃~ 70°C

   Operating Humidity
   5%~95% (Non condensation)

   Storage Humidity
   5%~95% (Non condensation)

   Shake: SSD applied
   1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1       hr/axis

   Shock: SSD applied
   10 G, IEC 60068-2-64, Half-sine wave, 11ms               duration

   Water-proof
   Front panel IP65




Features:

1.Versatile Installation Options: This all-in-one PC allows for flexible installation methods, including embedding it directly into surfaces,
hanging it on walls, or placing it on desktops, providing users with multiple placement options to suit their specific needs and space constraints.
2.IP65 Protection Rating: Equipped with an IP65 rating, this industrial monitor ensures protection against dust ingress and low-pressure water jets,
making it ideal for use in harsh environments or areas prone to dust and moisture, such as factories, warehouses, and outdoor installations.
3.Robust Sheet Metal Frame: The durable sheet metal frame not only provides a sleek appearance but also contributes to its
resistance to impacts and corrosion, ensuring long-term reliability and stability even in challenging conditions.
4.Resistive Touchscreen Technology: The touchscreen monitor employs resistive technology, offering accurate and reliable input recognition,
even when used with gloves or styluses, making it ideal for applications requiring precision and ease of use, such as industrial control systems,
data entry, and point-of-sale terminals.
5.Wide Range of Applications: This industrial-grade computer is well-suited for a variety of industries, including manufacturing, automation,
transportation, and more. Its robust design and advanced features make it perfect for control systems, data acquisition, process monitoring,
and human-machine interface (HMI) solutions.
All In One Wide Screen 10.1 Inch IP65 Industrial PC 10 Points Resisitive Touch Screen 0
