Place of Origin:	Guangdong, China
Brand Name:	Shine Star/OEM
Certification:	CE-LVD, CE-EMC, FCC, ROHS, ISO9001
Model Number:	SY550F

Minimum Order Quantity:	1 unit
Price:	To be negotiated
Packaging Details:	Depend on the final design you choose
Delivery Time:	15 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	10000 Pieces per month

Application:	Indoor, Outdoor, Semi-outdoor	Logo:	OEM/customized
Touch Screen As Option:	Capacitive Touchscreen	Installation:	Foldable, Free Standing
Viewing Angle:	89/89/89/89	Response Time:	8ms
Input Voltage:	AC100-240V	Port:	China Any Port, Shenzhen, Hongkong, Guangzhou

Display Panel Details	Display panel brand	LG,Samsung,AUO,Chimei,etc... original brand new and grade A+
Display Panel Details		Size	55 inch
Customize Frame Color	Black, white, silvery, golden as options
Body Material	Durable aluminum frame + tempered glass to protect LCD panel against external impacts
Functions Specifications as options as below
Single Player	Plug in a TF memory card or USB drive to automatically loop playing (without PC os), support timer ON/OFF, video, pictures, music, play list, split screen display function etc...
Display Panel Details	Dispaly ratio	16:9
		Dimension	180078886.35 mm (can be customized)
		Display area	1209.6X680.4 mm
		Screen resolution	3840*2160
		Output resolution	1080P / 4K
		Colour	1.07B(10bit)
		Brightness	350nits(can be customized)
		Contrast	5000:1
Function Options	Option 1	HDMI,VGA,AV input,and 1 USB multimedia palyer port
	Option 2	Android OS Wireless 3G/4G network management function(GPS as option)
	Option 3	X86/Windows OS/Linux OS Wireless 3G/4G network management function(GPS as option)
Touch Screen (Multi-Points)	Detection method	Capacitive touch,Multi-points, 10 points
		Position accuracy	Approximately 3 mm absolute, 1 mm relative. No drift
		Alignment	Software drivers provide a calibration facility
		Sensitivity	Can be programmed for different thickness of glass and even use with gloved hands.
				Standard configuration functions with non-metalized.
				single construction glass 16mm thick. Double glazing option up to 25mm available
		Speed of response	Depends upon material thickness. Typically 50 to 100ms
		Output	USB 3.0
		Software compatibility	Drivers are available for Windows Operating Systems
		Temperature range	Better than -10 to +60°C
		Humidity controller	0% to 95%. Unaffected by condensation
Metal Case	Material	Aluminum frame + metal casing + toughened glass
		Surface	Metal case with powder burning; tempered glass to protect LCD panel
		Speaker	25W; 210W built-in stereo speakers as options
		Heat dispersion	Built-in heat sink
		Network I/O	RJ-45
		Reset button	External reset button for ease of operation
		Extension	Mini Printer or A4 laser printer, Camera, Coin acceptor, Biology fingerprint recognizer, IC/ID card reader, Standard US Keyboard or metal explode proof, keyboard, 16bit Metal Keyboard, Infrared receiver, 2/3 track Magnetic Card reader, Explode proof metal
