| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | Shine Star/OEM |
| Certification: | CE-LVD, CE-EMC, FCC, ROHS, ISO9001 |
| Model Number: | SY550FRT |
| Minimum Order Quantity: | 1 unit |
| Price: | To be negotiated |
| Packaging Details: | Aluminum profiles+sheet metal |
| Delivery Time: | 15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 Pieces per month |
| Application: | Indoor, Outdoor, Semi-outdoor | Color: | Black, White, Silver Etc... |
|---|---|---|---|
| Full HD 1080P/4K: | Support | Network Function: | Wired LAN,WIFI,3G 4G |
| Resolution: | 3840*2160 | Brightness: | 350 Cd/m2 (upto 3500 Cd/m2 High Brightness As Options) |
| Viewing Angle: | 178/178 | Port: | All Of China Port |
|
Display Panel Details
|
Size
|
55inch
|
|
|
Dispaly ratio
|
16:9
|
|
Response time
|
8ms
|
|
|
|
Refresh frequency
|
60Hz
|
|
|
Colour
|
1.07B(10bit)
|
|
|
NTSC(Typ)
|
72% NTSC
|
|
|
Contrast Ratio
|
4000:1
|
|
Infrared Touch Parameters
|
Driver method
|
Driver free
|
|
|
Touch points
|
24
|
|
|
Writing points
|
5
|
|
Interpolation resolution
|
32767(W)*32767(D)
|
|
|
Response time
|
≤5ms
|
|
|
Frame rate
|
≥100Hz
|
|
|
Touch accuracy
|
±1mm
|
|
|
Minimum object sizes for touch
|
6mm
|
|
|
Interface
|
USB2.0+Serial Port
|
|
|
Working voltage
|
DC 5V±200mV
|
|
|
Average current
|
≤300mA
|
|
|
Support system
|
Windows10/Windows8/Windows7/Windows XP/Android/Linux/Mac OS X/Chrome
|
|
|
Writing style
|
Fingers,touch pens and other opaque objects
|
|
|
Environmental Factor
|
Operate temperature
|
-10℃~60℃
|
|
Operate humidity
|
10%~90%RH
|
|
|
Storage temperature
|
-10℃~70℃
|
|
|
Storage humidity
|
10%~90%RH
|
|
|
Altitude
|
Below 5000 meters
|
|
|
Power Supply Parameters
|
Model
|
SY550FRT
|
|
Power input
|
100-240V~50/60Hz
|
|
|
LED output power
|
≤75W
|
|
|
12V output power
|
≤75W
|
|
|
Use
|
Advertising publish, retail store, shopping mall, display of dishes, welcome display,
self-service business, exhibition hall, wayfinding, airport, subway, elevator, Restaurant
and hotel supplies, education, medical treatment
|
|
For more order quantity more discount more shipping options, OEM/ODM service,
Pls directly contact with us for more offers and details. Thank you very much!
