Place of Origin:	Guangdong, China
Brand Name:	WXYUAN
Certification:	CE FCC ROHS
Model Number:	WB215M-01

Minimum Order Quantity:	1 unit
Price:	Negotiable
Packaging Details:	(bubble bag+soft pearl wool wrap) carton+plywood box
Delivery Time:	5-22 days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	10000 Piece/Pieces per Month

Application:	Vehicle, Bus, Coach, Metro, Subway, Train, Taxi, Car	Display Ratio:	16:9
Installation Type:	Roof Mounting / Rear Mounting, Roof Mounting / Rear Mounting	Resolution:	1920x1080
View Angle（H/V）:	178/178	Full HD 1080P:	Support
Input Voltage:	DC 6V-36V	Material:	Metal Case + Toughened Glass Panel
Highlight:	with mounting bracket bus lcd monitor , with mounting bracket bus lcd advertising , 1920x1080 bus lcd monitor

Display Panel Details	Display panel brand	LG,Samsung,AUO,Chimei,etc... original brand new & grade A+
Display Panel Details		Size	7 inch to 85 inch
Decoding Details	video format	JPG.PNG.BMP.AVI.MPG.MP4.WMV.MOV.MP3.WAV.TXT.GZ.IMG.PDF..
		HD 1080P	Support
		Picture format	JPG,PNG,BMP, etc...
		Text	Txt...
		Audio format	MP3, WAV...
Interfaces	Option 1	SD + USB ports (support HDMI, VGA, AV input ports as option)
		Option 2	Android, Linux, Windows 7/10/XP/11 OS as options etc...
		Option 3	USB port + 8GB built-in memory
General Specifications	Program Update	USB automatically update, manual update
	Playlist	Support
	Break-point memory	Support
	Built-in speaker	2 * 2W, 2 * 5W , 2 * 10W as options
	Scrolling caption	Support
	Calendar	Support
	Inter-cut	Support,fixed time inter-cut
	Anti-theft lock	Support
	Split screen display	Can be set split-screen 1to8 area for broadcasting video w/ photo, w/ other display of logo/ date/ weather/ roll-text or subtitles.

Optional Functions: Open frame ,Touch screen, Motion sensor, wifi/4G/RJ45 network function, Android/Windows/Linux OS etc......
The machine operating temperature: -10~75°C,Storage Temperature:-10~75°C.
Advertising Features:
1.Application fields: Can be widely used in hotels, office buildings, the elevator, the exhibition site, entertainment and leisure facilities, but also in the subway station, train stations, airports, shopping malls, supermarkets, chain stores, specialty stores, convenience stores, promotional counters and other occasions etc......
2.Outer shell is made of extra good quality of metal material, which is painted by powder-spray craft work.
3.Support shockproof and dust proof function.
4.Adopts high transparent tempered glass as protection layer toprevent lcd/led panel being broken or distorted.
5.Locking system for anti-thieves, prevented the storage devices ( SD/CF cards ) and whole machine from being stolen.
6.Support IR Remote controller, user can use remote controller to operate the whole lcd. ( key buttons is optional )
7.switch on automatically loop playback, support files in mixed,pictures,video,music.
8.support MPEG4(avi: div-x,x-vid),MPEG2(dvd,vob,MPG2),MPEG1(vcd,dat,MPG1),JPEG,MP3 format etc...
9. support OTG copy function,USB file automatically COPY to memory card.
10.automatic power-on/off, rolling caption, time display, playlists, vertica/horizontal screen, time and volume functions etc...
11. Image playback: rotate, slide show, background music etc...
12.Support 5 groups of auto power-on/off timer, able to set those 5 groups of time 1 day and 7 days in 1week.
13.Automatically generate play logs, file playback status query
14. support the specified file playing in a specific time spot (option)
