| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | Shine Star/OEM |
| Certification: | CE-LVD, CE-EMC, FCC, ROHS, ISO9001 |
| Model Number: | SAP-098-001 |
| Minimum Order Quantity: | 1 unit |
| Price: | negotiable |
| Packaging Details: | Depend on the final design you choose |
| Delivery Time: | 15 work days |
| Payment Terms: | D/A, D/P, L/C, T/T, MoneyGram, Western Union |
| Supply Ability: | 10000 units per month |
| Panel Type: | LED | Panel Size: | 98 Inch |
|---|---|---|---|
| Resolution: | 3840*2160 | Writing Method: | Pen/finger Touch |
| Product Dimension: | 2216.01x1313.5x96.33mm | Touch Screen: | Multi Touchscreen 20-points |
| Full HD 1080P / UHD 4K: | Support | Brightness: | 400cd/m2 |
| Highlight: | 100 inch smart board 500cd/m2,100 inch interactive led flat panel,interactive led flat panel 500cd/m2 |
||
|
Display Panel Details
|
Size
|
98 inch
|
|
|
|
Display panel brand
|
LG,Samsung,AUO,Chimei,etc... original brand new and grade A+
|
|
|
Customize Frame Color
|
Black, green, pink, ivory, wine red, blue, violet..
|
|
|
|
Body Material
|
Durable aluminum frame + tempered glass to protect LCD panel against external impacts
|
|
|
|
Android OS
|
Chipset
|
T982, Quad-core ARM Cortex-A55
|
|
|
|
Chipset Frequency
|
1.5Ghz
|
|
|
|
GPU
|
Mali-G52 MP2(2EE)
|
|
|
|
Ram and Flash
|
4GB DDR4 NAND FLASH: 32GB
|
|
|
|
Operation System
|
Android 13
|
|
|
|
WiFi Network
|
IEEE802.11an 2.4GHz
|
|
|
|
Mirroring hotspots
|
Dual bands (IEEE802.11 a/b/g/n Dual Band 2.4GHz/5 GHz)
|
|
|
|
Bluetooth
|
BT:v2.1+EDR/BT V3.0/BT V3.0+HS/BT V4.0
|
|
|
Touch Screen (Multi-Points)
|
Detection Method
|
Infrared touch,Multi-points, 20-points
|
|
|
|
Position accuracy
|
Approximately 3 mm absolute, 1 mm relative. No drift
|
|
|
|
Alignment
|
Software drivers provide a calibration facility
|
|
|
|
EMC
|
EN55022:1998 + A1 + A2 EN55024:1998 + A1 + A2
|
|
|
|
|
This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions
|
|
|
|
|
(1) This device may not cause harmful interference
(2) This device must accept any interference received, including interference that may cause undesired operation |
|
|
|
Speed of response
|
Depends upon material thickness. Typically 50 to 100ms
|
|
|
|
Output
|
USB 2.0
|
|
|
|
Software Compatibility
|
Drivers are available for Windows Operating Systems
|
|
|
|
Temperature range
|
Better than -10 to +70°C
|
|
|
|
Humidity Controller
|
0% to 95%. Unaffected by condensation
|
|
|
Metal Case
|
Material
|
Aluminum frame + metal casing + toughened glass
|
|
|
|
Surface
|
Metal case with powder burning; tempered glass to protect LCD panel
|
|
|
|
Speaker
|
2*12W built-in stereo speakers
|
|
|
|
Heat Dispersion
|
Built-in heat sink
|
|
|
|
Network I/O
|
In the rear: USB for touch, RJ45 Lan port, AV in, AV out, Earphone port, SPDIF out, HDMI input port, DB9 RS232, USB2.0, USB3.0, OPS interface port
In the front panel: 2x USB2.0, USB3.0, HDMI input, USB for touch
|
|
|
|
Reset Button
|
External reset button for ease of operation
|
|
|
|
Extension
|
Mini Printer or A4 laser printer, Camera, Coin acceptor, Biology fingerprint recognizer, IC/ID card reader, Standard US Keyboard or metal explode proof, keyboard, 16bit Metal Keyboard, Infrared receiver, 2/3 track Magnetic Card reader, Explode proof metal
|
|
For more order quantity more discount more shipping options, OEM/ODM service,
Pls directly contact with us for more offers and details. Thank you very much!
