| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | Shine Star/oem |
| Certification: | CE-LVD, CE-EMC, FCC, ROHS, ISO9001 |
| Model Number: | SAP-055-006 |
| Minimum Order Quantity: | 1unit |
| Price: | negotiable |
| Packaging Details: | K5K8K Kraft Paper + EPE, Outer Wooden Case(optional) |
| Delivery Time: | 15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 units per month |
| Product Name: | Smart Interactive Whiteboard | Color: | 16.7M/1.06B |
|---|---|---|---|
| Aspect Ratio: | 16:9 | Resolution: | 3840*2160 |
| Writing Method: | Pen/finger Touch | Active Area: | 1209.6X680.4 Mm |
| Machine Body Size: | 1258*757*84.8mm | Viewing Angle: | 178°(HV) |
|
Display Panel Details
|
Display panel brand
|
LG,Samsung,AUO,Chimei,etc...
|
|
|
|
Size
|
55, 65, 75, 86 and 98 inch as options
|
|
|
Customize Frame Color
|
Black, white, silvery, golden as options
|
|
|
|
Body material
|
Durable aluminum frame + tempered glass to protect LCD panel against external impacts
|
|
|
|
Android OS
|
CPU
|
V100
|
|
|
|
RAM
|
4GB
|
|
|
|
Memory
|
32GB
|
|
|
|
GPU
|
Mali-G52 MP2(2EE)
|
|
|
|
OS
|
Android 13
|
|
|
|
WiFi
|
150Mbps-1000Mbps 802.11b/n/g Wifi Integated
|
|
|
|
Bluetooth
|
V2.1+EDR/BT V3.0/BT V3.0+HS/BT V4.0
|
|
|
|
Remote Distance
|
12 meters
|
|
|
OPS
|
CPU
|
I3/I5/I7
|
|
|
HDD
|
128GB(SSD)
|
||
|
Graphics
|
Intel ®HD Graphics
|
||
|
Touch Screen (Multi-Points)
|
Detection Method
|
Capacitive touch, Multi-points, 10 points
|
|
|
|
Position accuracy
|
Approximately 3 mm absolute, 1 mm relative. No drift
|
|
|
|
Alignment
|
Software drivers provide a calibration facility
|
|
|
|
Sensitivity
|
Can be programmed for different thickness of glass and even use with gloved hands
|
|
|
|
|
Standard configuration functions with non-metalized
|
|
|
|
|
Single construction glass 16mm thick. Double glazing option up to 25mm available
|
|
|
|
Speed of response
|
Depends upon material thickness. Typically 50 to 100ms
|
|
|
|
Output
|
USB 2.0
|
|
|
|
Software Compatibility
|
Drivers are available for Windows/Android/Linux Operating Systems
|
|
|
|
Temperature range
|
Better than -10 to +70°C
|
|
|
|
Humidity Controller
|
0% to 95%. Unaffected by condensation
|
|
|
Metal Case
|
Material
|
Aluminum frame + metal casing + toughened glass
|
|
|
|
Surface
|
Metal case with powder burning; tempered glass to protect LCD panel
|
|
|
|
Speaker
|
2*12W built-in stereo speakers
|
|
|
|
Heat Dispersion
|
Built-in heat sink
|
|
|
|
Network I/O
|
In the rear: USB for touch, RJ45 Lan port, AV in, AV out, Earphone port, SPDIF out, HDMI input port, DB9 RS232, USB2.0, USB3.0, OPS interface port
In the front panel: 2x USB2.0, USB3.0, HDMI input, USB for touch
|
|
|
|
Reset Button
|
External reset button for ease of operation
|
|
|
|
Extension
|
Mini Printer or A4 laser printer, Camera, Coin acceptor, Biology fingerprint recognizer, IC/ID card reader, Standard US Keyboard or metal explode proof, keyboard, 16bit Metal Keyboard, Infrared receiver, 2/3 track Magnetic Card reader, Explode proof metal
|
|
For more order quantity more discount more shipping options, OEM/ODM service,
Pls directly contact with us for more offers and details. Thank you very much!
