LCD Screen	10.1 Inch (16:10 LED)
Display Area	216.96*135.6mm
Screen Resolution	1280*800
Viewing Angle	178/178
Brightness	350cd/㎡ (higher brightness is available as option)
Contrast	1000:1
Colour	16.7M

Display Panel Details	display panel brand	LG,Samsung,AUO,Chimei,etc... original brand new & grade A+
Display Panel Details		Size	7 inch to 55 inch
Customize Frame Color	Black, white, green, pink, ivory, wine red, blue, violet, ......can be customized
Body Material	Durable aluminum frame + tempered glass to protect LCD panel against external impacts. front panel compliant NEMA / IP65 waterproof and dustproof standard,so that it can adapt to the harsh industrial site work environment, the most suitable for factory automation, machinery manufacturing, CNC equipment, textile equipment, communication networks, power automation and other industrial applications.
PC Configuration	Chipset	X86 main board: Intel i3 i5 i7/ Celeron J1900/J1800/J4125/J6412, ARM: RK3288 RK3399 RK3566 RK3568...... as options
		Chipset Frequency	Quad core upto 5Ghz
		Chipset integrated	Intel Bay trail SOC
		Ram	2GB/4GB DDR4 SDRAM (16GB max)
		Hard Disk	64GB high speed solid state disk upto 3TB (optional)
		WiFi	802.11b/n/g Wifi Integrated, (2.4G & 5Ghz dual WIIF module as option)
PC Configuration	Audio	Realtek HD ALC662 HD Line-In/Line-Out/Speaker out with 1W AMP Circuit
		Ethernet ports	Realtek RTL8111EL PCI-E Gigabit Ethernet LAN RJ45 port
		HDMI/VGA ports	Default *1 (options)
		COM ports	Default *2 COM (RS485 RS232 RS422 as options)
		USB ports	Default 4 USB (3USB2.0; 1*USB3.0) (options)
Operation System	Win7, Win7 Embedded, Win8, Win10, Ubuntu, VXWORKS, QNX, Linux, Android etc...
Touch Screen	TouchScreen Type	Resistive(4-wire/5-wire); capacitive; SAW/IR as options
		TouchScreen Interface	Serial (RS232) or USB or COM as options
		Surface Hardness	Mohs' Number 7; Transmittance >75%
Power Supply	Input Voltage	DC12V or 24V
Power Supply		Output Rating	≦15W
Environmental	Work Temperature	-20℃ ~ 60°C (-4~140°F)
		Storage Temperature	-30℃ ~ 80°C (-22 ~ 176°F)
		Relative humidity	5%~95% (Non condensation)
		Shake: SSD applied	1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
		Shock: SSD applied	10 G, IEC 60068-2-64, Half-sine wave, 11ms duration
		EMC	CE/FCC Class A
		Water-proof	Front panel IP65

Features.

Our industrial panel pc are fully-integrated‚ waterproof and dustproof that combine high-performance different touch screen technologies in industrial-grade TFT-LCD flat panels, with sleek, IP65 / NEMA 4-4 x Ingress rating flat front surface industrial design.
Our industrial touch panel PC provide reliability, durability, and long expected product life. Impervious to environmental conditions such as liquid spills, splashes and wash-downs, these screens are the most contamination-resistant units available in the market. Our industrial IP65/ NEMA 4 touch computer are designed for process control, food processing equipment, machine control, human interface, automation equipment and in-vehicle use applications. Our panel pc have 7 inches to 55 inches.

Specialties.

1. Long lasting product cycle for continuity thru all phases of project rollouts and servicing.
2. Exceptional quality and highly engineered industrial monitors.
3. Delivers drift-free operation with lifetime of more than 35 million finger touches like resistive, IR, SAW, Scap, Pcap, etc...
4. All steel construction designed for harsh and industrial environments.
5. Robust design with aluminum NEMA 4/ IP65 front panel or fully steel enclosed chassis.
6. Meets NEMA 4/4x/12 and IP65 standards.
7. Multiple mounting options (75*100mm VESA mount and clamps mounting).
8. Accuracy in high-use applications.
9. Supports Win7/10/11/XP, Linux OS, Android, Mac OS, Ubuntu, Debian.
10. CE, FCC, RoHS, ISO9001:2008 compliance.
11. VGA, DVI, HDMI, AV, S-Video, BNC multiple inputs/outputs optional.
12. Wide operating temperature from -30 to 80 degrees optional and supports 7/24 running.

Place of Origin:	Guangdong, China
Brand Name:	WXYUAN
Certification:	CE FCC ROHS ISO9001
Model Number:	SYD-101-09

Minimum Order Quantity:	1 unit
Price:	Negotiable
Packaging Details:	(bubble bag+soft pearl wool wrap) carton+plywood box
Delivery Time:	15 days
Payment Terms:	D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability:	1000 Piece/Pieces per Month

Type:	Panel PC	Input Voltage:	12V 24V As Options
Network Function:	Wired LAN RJ45,wireless WIFI, 4G Network	Touch Screen:	Capacitive 10-point Multi Point
Camera:	USB, HDMI, Ethernet, COM, RJ45 Lan	RFID Reading Distance:	Up To 10cm
RFID Protocol:	ISO 14443A/B, ISO 15693	RFID Reader:	Yes
Supported Cards:	ISO14443A, ISO14443B, ISO15693	Optional Function:	Support Bluetoooth
Ports:	USB 3.0, HDMI, Ethernet	Application:	Indoor, Outdoor, Semi-outdoor
Communication:	Ethernet, Wi-Fi, Bluetooth
