7 Inch Android Industrial Panel PC With Touchscreen Support Ubuntu Debian Linux OS

Basic Information
Place of Origin: Guangdong, China
Brand Name: WXYUAN
Certification: CE FCC ROHS
Model Number: SY007A-01
Minimum Order Quantity: 1 unit
Price: negotiable
Packaging Details: (bubble bag+soft pearl wool wrap) carton+plywood box<br>aluminium embedded terminal panel PC touch screen industrie computer fanless support Win7/10/11/XP Android Linux
Delivery Time: 5-22 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3070 Piece/Pieces per Month
Connectivity: WiFi, Bluetooth, Ethernet Material: Aluminium Alloy Shell
Operation: 7*24 Hours Touch Points: 10 Ponits
Operating_Temperature: -20°C To 60°C Ports: USB, HDMI, RS232
Mounting_Options: VESA Mount, Panel Mount Certifications: CE, FCC, RoHS
Highlight:

aluminium alloy shell android industrial panel pc

,

aluminium alloy shell android industrial tablet pc

7 Inch Android Industrial Panel PC With Touchscreen Support Ubuntu Debian Linux OS



Display Panel Details
display panel brand
LG,Samsung,AUO,Chimei,etc... original brand new & grade A+

Size
7 inch to 55 inch
Customize Frame Color
Black, white, green, pink, ivory, wine red, blue, violet, ......can be customized

body material
Durable aluminum frame & tempered glass to protect LCD panel against external impacts. front panel compliant NEMA / IP65 waterproof and dustproof standard,so that it can adapt to the harsh industrial site work environment, the most suitable for factory automation, machinery manufacturing, CNC equipment, textile equipment, communication networks, power automation and other industrial applications.

PC configuration
Chipset:
Rockchip RK3566 RK3568 RK3588 RK3399...... as options

Chipset Frequency:
Quad core upto 2.66Ghz

Chipset integrated
Cortex-A17+GPU Mail-T764, and others as option etc...

Ram:
4GB DDR4 SDRAM (16GB max)

Flash Memory:
16GB/32GB/64GB high speed (optional)

WiFi
802.11b/n/g Wifi Integated
PC configuration
Audio
Realtek HD ALC662 HD
Line-In/Line-Out/Speaker out with 1W AMP Circuit

Ethernet ports
Realtek RTL8111EL PCI-E Gigabit Ethernet LAN RJ45 port

HDMI ports
Default *1 (options)

COM ports
Default *2 COM (options)

USB ports
Default *2 USB (1*USB3.0; 1*USB-OTG) (options)
Operation System:
Linux Ubuntu Debian OS Android 11/13 OS etc......

Touch Screen
TouchScreen Type
10-Point capacitive touchscreen as options

TouchScreen interface
Serial (RS232) or USB or COM as options

Surface Hardness
Mohs' Number 7; Transmittance >75%
Power Supply
Input Voltage
DC12V or 24V

Output Rating
≦10W
Environmental
Work Temperature
-20 ~ 60°C (-4~140°F)

Storage Temperature
-30 ~ 80°C (-22 ~ 176°F)

Relative humidity
5~95% (Non condensation)

Shake: SSD applied
1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

Shock: SSD applied
10 G, IEC 60068-2-64, Half-sine wave, 11ms duration

EMC
CE/FCC Class A

Water-proof
Front panel IP65



Features.

Our industrial panel PC are fully-integrated‚ waterproof and dustproof that combine high-performance different touch screen technologies in industrial-grade TFT-LCD flat panels, with sleek, IP65 / NEMA 4-4 x Ingress rating flat front surface industrial design.
Our industrial PC provide reliability, durability, and long expected product life. Impervious to environmental conditions such as liquid spills, splashes and wash-downs, these screens are the most contamination-resistant units available in the market. Our industrial IP65/ NEMA 4 touch computer are designed for process control, food processing equipment, machine control, human interface, automation equipment and in-vehicle use applications. Our panel PC have 7 inches to 55 inches.

Specialties.

1. Long lasting product cycle for continuity thru all phases of project rollouts and servicing
2. Exceptional quality and highly engineered industrial monitors
3. Delivers drift-free operation with lifetime of more than 35 million finger touches like resistive, IR, SAW, Scap, Pcap, etc
4. All steel construction designed for harsh and industrial environments
5. Robust design with aluminum NEMA 4/ IP65 front panel or fully steel enclosed chassis
6. Meets NEMA 4/4x/12 and IP65 standards
7. Multiple mounting options (75*100mm VESA mount and clamps mounting)
8. Accuracy in high-use applications
9. Supports Windows, Linux OS, Android, Mac OS, Ubuntu, Debian etc......
10. CE, FCC, RoHS, ISO9001:2008 compliance.
11. VGA, DVI, HDMI, AV, S-Video, BNC multiple inputs/outputs optional
12. Wide operating temperature from -30 to 80 degrees optional and supports 7/24 running
