| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | Shine Star/OEM |
| Certification: | CE-LVD, CE-EMC, FCC, ROHS, ISO9001 |
| Model Number: | SY084 |
| Minimum Order Quantity: | 1 unit |
| Price: | To be negotiated |
| Packaging Details: | Depend on the final design you choose |
| Delivery Time: | 15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 units per month |
| Type: | TFT LCD LED | Logo: | OEM/Customized |
|---|---|---|---|
| Metal Housing+Tempered Glass: | Aluminum Alloy Frame+tempered Glass | Resolution: | 800*600 |
| Brightness: | 300 Cd/m2 (upto 3500 Cd/m2 High Brightness As Options) | Built-in Speakers: | Yes |
| Wireless Connectivity: | WiFi, Bluetooth | Port: | All China Ports |
| Highlight: | 10'' Industrial Tablet PC Touch Screen,10.1'' Industrial Tablet PC Touch Screen,intel J1800 Fanless Industrial PC |
||
|
Display Panel Details
|
Display Panel Brand
|
LG,Samsung,AUO,Chimei,etc... original brand new grade A+
|
|
|
|
Size
|
8.4 inch
|
|
|
Customize Frame Color
|
Black, white, green, pink, ivory, wine red, blue, violet, ......can be customized
|
|
|
|
Body Material
|
Aluminum alloy frame+tempered glass to protect the LCD panel from external impacts. The front panel meets NEMA/IP65 waterproof and dustproof standards, making it suitable for harsh industrial working environments and most suitable for industrial applications such as factory automation, mechanical manufacturing, CNC equipment, textile equipment, communication networks, and power automation.
|
|
|
|
PC Configuration
|
CPU
|
CPU Rockchip 3566 Quad Core
|
|
|
|
Chipset Frequency
|
2.0Ghz
|
|
|
|
GPU
|
Mali-G52-2EE
|
|
|
|
Ram and Flash
|
4GB DDR3 SDRAM and NAND FLASH: 32GB
|
|
|
|
Operation System
|
Android 11.0 / Linux Debian 10/ Ubuntu 20.04 OS as options
|
|
|
|
WiFi
|
802.11n Wifi Integated
|
|
|
Display Screen Parameters
|
Display Ratio
|
4:3
|
|
|
|
Contrast Ratio
|
500:1
|
|
|
|
Brightness
|
300 cd/m2 (upto 3500 cd/m2 high brightness as options)
|
|
|
|
Colour
|
262K/16.7M
|
|
|
|
Resolution
|
800*600
|
|
|
Touch Screen
|
Touch Screen Type
|
Capacitive;Resistive(4-wire/5-wire); SAW/IR as options
|
|
|
|
Touch Screen Interface
|
Serial (RS232) or USB or COM as options
|
|
|
|
Surface Hardness
|
6H
|
|
|
Power
|
Standby
|
≤3W
|
|
|
|
Working
|
≦15W
|
|
|
Metal Case
|
Interface
|
DC power port (12V), Audio, HDMI out, RJ45 Lan port, TF card slot, USB3.0, USB-OTG
|
|
|
|
Speaker
|
2*2W built-in stereo speakers
|
|
|
|
Heat Dispersion
|
Heat sink
|
|
|
|
Network I/O
|
RJ-45 *1
|
|
|
|
Reset Button
|
External reset button for ease of operation
|
|
|
|
Extension
|
Mini Printer or A4 laser printer, Camera, Coin acceptor, Biology fingerprint recognizer, IC/ID card reader, Standard US Keyboard or metal explode proof, keyboard, 16bit Metal Keyboard, Infrared receiver, 2/3 track Magnetic Card reader, Explode proof metal
|
|
|
|
Water-proof
|
Front panel IP65
|
|
