Name: 10.1 Inch IP65 Industrial All In One PC Capacitive Touch Screen 16:10 Display Ratio
Brand: Shenzhen Wang Xin Yuan Electronic Technology Co., Ltd.
SKU: SY101
Price: 425.00 USD
Availability: InStock

10.1 Inch IP65 Industrial All In One PC Capacitive Touch Screen 16:10 Display Ratio

Basic Information

Place of Origin:	Guangdong, China
Brand Name:	Shine Star/OEM
Certification:	CE-LVD, CE-EMC, FCC, ROHS, ISO9001
Model Number:	SY101

Minimum Order Quantity:	1 unit
Price:	To be negotiated
Packaging Details:	Depend on the final design you choose
Delivery Time:	15 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000 units per month

Contact Now Chat Now

Display Ratio:

16:10 LED

Logo:

OEM/Customized

Touch Screen:

Capacitive Touch,Multi-points, 10-points

Resolution:

1280*800

Built-in Speakers:

Yes

Brightness:

300 Cd/m2 (upto 3500 Cd/m2 High Brightness As Options)

Input Voltage:

12V 24V As Options

Port:

All China Ports

Highlight:

Industrial Android Panel PC RK3568

Industrial Android Panel PC RK3399

19'' Resistive Touch Screen android panel pc

Product Description

10.1 Inch IP65 Industrial All In One Capacitive Touch Screen 16:10 Display Ratio

Product specifications:

Display Panel Details	Display Panel Brand	LG,Samsung,AUO,Chimei,etc... original brand new and grade A+
Display Panel Details	Size	10.1 inch
Customize Frame Color	Black, white, green, pink, ivory, wine red, blue, violet, ......can be customized
Body Material	Aluminum alloy frame+tempered glass to protect the LCD panel from external impacts. The front panel meets NEMA/IP65 waterproof and dustproof standards, making it suitable for harsh industrial working environments and most suitable for industrial applications such as factory automation, mechanical manufacturing, CNC equipment, textile equipment, communication networks, and power automation.
Display Screen Parameters	Display Ratio	16:10 LED
	Contrast Ratio	900:1
	Brightness	300 cd/m2 (upto 3500 cd/m2 high brightness as options)
	Colour	16.7M
	Resolution	1280*800
	Viewing Angle	89/89/89/89
PC Configuration	CPU	Intel® J1900 quad core (1.99GHz)
	RAM	DDR III / 4GB
	HDD	128GB SSD
	Chipset	Intel Bay trail SOC
	WiFi	802.11n Wifi Integated
Operation System	Android,Win7, Win7 Embedded, Win8, Win10, Ubuntu, VXWORKS, QNX, Linux,etc...
Touch Screen	Touch Screen Type	Capacitive;Resistive(4-wire/5-wire); SAW/IR as options
	Touch Screen Interface	Serial (RS232) or USB or COM as options
	Surface Hardness	6H
Power	Standby	≦3W
Power	Working	≦20W
Metal Case	Interface	DC power port (12V), HDMI, VGA, USB3.0 2; USB2.0 2; RJ45 Ethernet Lan *1; LIN out; Mic in; (1-2 RS232 ports as options)
	Speaker	2*2W built-in stereo speakers
	Heat Dispersion	Heat sink
	Network I/O	RJ-45
	Reset Button	External reset button for ease of operation
	Extension	Mini Printer or A4 laser printer, Camera, Coin acceptor, Biology fingerprint recognizer, IC/ID card reader, Standard US Keyboard or metal explode proof, keyboard, 16bit Metal Keyboard, Infrared receiver, 2/3 track Magnetic Card reader, Explode proof metal
	Water proof	Front panel IP65

Features:

Our industrial panel pc are fully-integrated‚ waterproof and dustproof that combine high-performance different touch screen technologies in

industrial-grade TFT-LCD flat panels, with sleek, IP65 / NEMA 4-4 x Ingress rating flat front surface industrial design.
Our industrial pc provide reliability, durability, and long expected product life. Impervious to environmental conditions such as liquid spills, splashes

and wash-downs, these screens are the most contamination-resistant units available in the market. Our industrial IP65/ NEMA 4 touch computer

are designed for process control, food processing equipment, machine control, human interface, automation equipment and in-vehicle use applications.

For more order quantity more discount more shipping options, OEM/ODM service,

Pls directly contact with us for more offers and details. Thank you very much!
