1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS

Basic Information
Place of Origin: Guangdong, China
Brand Name: Shine Star/OEM
Certification: CE-LVD, CE-EMC, FCC, ROHS, ISO9001
Model Number: SA215-0010
Minimum Order Quantity: 1 unit
Price: To be negotiated
Packaging Details: Depend on the final design you choose
Delivery Time: 15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 units per month
Panel Size: 21.5" 22" Max Resolution: 1920x1080
Logo: OEM/customized Metal Shape: Can Be Customized
Touch Screen: Option Full HD 1080P: Support
Network Function: Wired LAN,WIFI,3G/4G OS: Android,Win10/11/XP, Linux As Option
Brightness: 350 Nits Viewing Angle: 178 /178
Input Voltage: AC 110V~240V Material: Metal Case + Toughened Glass Panel
Port: Shenzhen/hongkong

Product Description

1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS

1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 0
Display Panel Details
display panel brand
LG,Samsung,AUO,Chimei,etc... original brand new & grade A+
Size
7 inch to 85 inch
Customize Frame Color
Black, white, green, pink, ivory, wine red, blue, violet
body material
Durable aluminum frame & tempered glass to protect LCD panel against external impacts
PC configuration
CPU
Intel ® i3 / i5 / i7 or RK2388 RK3399 etc......
RAM
DDR III / 1333 / 4G-8G
HDD
SSD 80GB -- 1TB
Chipset
82NM70 Chipset
OS
Win7/10/11/XP/Linux/others or Android OS
WiFi
350Mbps 802.11b/n/g Wifi Integated
Graphics
Intel ®GMA HD4000
Audio
HD 8-channel (7.1) audio subsystem
Touch Screen       (Multi-Points)
Detection Method
Capacitive touchscreen , 10-points
Position accuracy
Approximately 3 mm absolute, 1 mm relative. No drift
Alignment
Software drivers provide a calibration facility
Sensitivity
Can be programmed for different thickness of glass and even use with gloved hands.
Standard configuration functions with non-metalized.
single construction glass 16mm thick. Double glazing option up to 25mm available
Speed of response
Depends upon material thickness. Typically 50 to 100ms
Output
USB 2.0
Software Compatibility
Drivers are available for Windows Operating Systems
Temperature range
Better than -10 to +70°C
Humidity Controller
0% to 95%. Unaffected by condensation
Metal Case
Material
Steel/metal & Tempered glass
Surface
Metal case with powder burning; tempered glass to protect LCD panel
Speaker
2*10W built-in stereo speakers;
Heat Dispersion
Built-in DC fan;
Network I/O
RJ-45;
Reset Button
External reset button for ease of operation;
Extension
Mini Printer or A4 laser printer, Camera, Coin acceptor, Biology fingerprint recognizer, IC/ID card reader, Standard US Keyboard or metal explode proof, keyboard, 16bit Metal Keyboard, Infrared receiver, 2/3 track Magnetic Card reader, Explode proof metal
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 1
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 2
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 3
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 4
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 5
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 6
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 7
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 8
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 9
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 10
Product Details

2-6mm Tempered Glass as protection surface



Metal Housing for public usage


Duable and anti-vandalism


Customized logo & body colour available


OEM/ODM on functions & shapes welcome

1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 11
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 12

Multi-point touch screen

Capacitive touch panel & IR touch panel are available

10 touch points

advertising / signage features


split screen display (video + pictures + music ...)
real time display
rolling captions
calendar
Weather


1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 13
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 14
Network System (WIFI, 3G/4G, RJ45)


* Can set several assistant of administrator with limits of authority.
* Can set fixed time download, real-time download. And keep broadcasting when downloading.
* Support terminal set password, for protect viciously control from outside.
* Support modify terminal IP by server software or by remote control.
* High definition, and support 1080P video.
* Control one or all terminals.
* Support 3 roll-text.
* Support play files & roll-text in the specified time, support playlist.
* Support play video with connected photo and roll-text.
* Can be set several clocks of power on and off.
* Support cut-in broadcasting.
* Support vertical type.

1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 15
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 16
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 17
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 18
Packing & Delivery
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 19

Plywood box


1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 20

Plywood box


1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 21

Plywood box


Our Service

Warranty:  12 months warranty & Life-time maintenance

Trade Terms: EX-Works, FOB, C&F, CIF

Payment terms : T/T, Western Union, PayPal, L/C, MoneyGram, Cash, Trade assurance.

Shipping: By sea, by air and by international express ......

Certifications
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 22
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 23
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 24
1920*1080 21.5 inch led backlight pos touch screen lcd pop up display with mini PC Win11/Android/ Linux OS 25
FAQ

1) Q:What is the minimum order quantity?

A:  Qty: 1 unit. Different order quantity different price.


2) Q:What payment methods your company accept?

A:We accept most often payment methods,but mainly accept bank wire transfer T/T, L/C at sight, Western Union.


3) Q:How long is the warranty time for your products?

A: We warranty 1 year for all of our products and supply life-time maintenance.


During 1 year warranty period, for small part defective,we will send replacement parts for free of charge to customers,so customers can replace defective parts by new parts by themselves. We also will pay for shipping cost. For big defective problem,customers have to ship back defective units to us and we will repair or replacement for them for free of charge. Customers will pay for shipping cost from their address to China and we will pay for shipping cost from China to customers' address.

For life-time maintenance (out of 1 year warranty period),any defective parts or units,customers will pay for replacement parts and shipping cost.We will charge a bottom cost for parts.

The man-made damage and misusing damage is not under warranty.


4) Q:I haven't done business with your company before,how can i trust your company?

A:Our company is a registered golden member on Alibaba sit for more than 15 years. We have many business partners and order histories all over the world.


5) Q:what's the shipment terms and delivery time of your company?

A: It depends on order quantity, shipping address and shipping methods.


6) Q:Do you give any discount ?

A: Different order quantity different price. We will always offer customers the lowest price based on the best quality.


7) Q:I would like to ask you if it's possible to have my logo on the product.

A: Logo printing service is available.
