embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display

Basic Information
Place of Origin: Guangdong, China
Brand Name: Shine Star/OEM
Certification: CE-LVD, CE-EMC, FCC, ROHS, ISO9001
Minimum Order Quantity: 1 unit
Price: To be negotiated
Packaging Details: Depend on the final design you choose
Delivery Time: 15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 units per month
Application: Indoor, Outdoor Type: LCD
Color: Black, White, Silver Etc... Supplier Type: Original Manufacturer, ODM, Agency, Retailer, Other, OEM
Media Available: Datasheet, Photo, EDA/CAD Models, Other Use: Advertising Publish, Retail Store, Shopping Mall, Display Of Dishes, Welcome Display, Self-service Business, Exhibition Hall, Wayfinding, Airport, Subway, Elevator, Restaurant & Hotel Supplies, Education, Medical Treatment
Specification: Stretch Bar, Digital Poster, Touch Screen, Video Wall, Kiosk Touch Screen Type: Capacitive, Touchscreen
Brightness: 350nits, 350nits, 350nits Display Ratio: 16:9, 16:9
Response Time: 1ms, 1ms Contrast Ratio: 2000:1, 2000:1
Lifespan (hours): 100000, 100000 Installation Type: VESA / Wall Mounting / Embedded, VESA / Wall Mounting / Embedded
HS Code: 8528591090 Resolution: 1366x768 / 1920x1080
View Angle(H/V): 178/178, 178/178 Logo: OEM
Network Management Function: LAN,WIFI,4G As Option HD 1080P: Support
Touch Screen: Option Metal Case: Can Be Customized
Protective Surface: Tempered Glass Viewing Angle: 89/89/89/89
Input Voltage: 110V-240V Operating System: Standalone/Android/Win7/8/10/Linux
Port: All Of China Port

embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display

embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 0

Product Description
- Digital Panel
- Cabinet: Plastic case
There is lock hole on the back.
- ABS housing available in customized color, available in standard black, white, or silver.
- Brand New LCD TFT Panel: AUO, INNOLUX, CHIMEI, Sharp, Toshiba, Samsung, LG
- Supports Music, Photo, Auto Play, and Replay in Loop
- Multi Language OSD: English, Japanese, Chinese etc.
- Supports Slide Show (interval mode: Interval time with 1, 3, 5, 10, 30, 60 seconds).
- Play through USB (2.0) / SD (High Speed) / CF Card
- Playback mode: File and folder repeat, choose to repeat playback one file or all the files.
- USB Update Content Directly in CF/SD Card
- Build-in clock and calendar function in the system of player.
- BGM (background music) mode.
- Build-in 2 High Quality Stereo Speakers: 5W x 2
- Anti-burglar Lock system
- Support Shockproof and Dustproof Function
- Timer on/off function: Support 5 groups of auto power-on / off timer. It is able to be set 5 groups of times per day and 7 days in one week.
- Power supply: AC 100V~240V, 50Hz/60Hz, Output working Voltage: 12V 4A.
- Fixation & Bracket: VESA 100mm x 100mm.
- Accessories: Power Cable x 1, User Manual x 1, Bracket x 1, Remote Control x 1, Anti-Burglar Cable x 1 (Optional).
- Working temperature: 0~40C- Working humidity: 20%~80%
- Storage temperature: -20~60C
- Storage humidity: 10%~95%
- We can customize according to the different advertising projects

File format:
AUDIO: MP3; File Suffixes: *. MP3
VIDEO: MPG1 (VCD), MPG2 (DVD/SVCD),
MPG-4 ASP (MPEG-5 Advanced Simple Profile video including GMC and QPEL support), M-JPEG;
File Suffixes: *. AVI, *. Dat, *...Vob, *. Mpg.
PHOTO: JPEG, PROGRESSIVE JPEG; File Suffixes: *. JPG

LCD panel specification:
Monitor Size/Profile Ratio: 19 inch Digital Panel / 16: 10
Display Resolution: WXGA (1440 X 900)
Active Area(mm): 408, 24(W)X255.15(H) mm2
Pixel Pitch (mm): 0.2835mm
Number of Colors: 16.7M (RGB 8 bits)
View Angle(R/L/T/B): 80/80/80/80
Brightness (CD/ m): 350CD/m
Contrast Ratio: 1000: 1
Response Time (ms) (at 25C) (Rising + Falling): 5 ms
Power Consumption (W): 23W
Interface: 2CH LVDS
Supply Voltage (V): 5 V
Light Source: CCFL
Outline Dimensions (mm): 428.0(W)X278.0(H)X18.5(D) mm3
Weight (g): 2500g

embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 1embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 2embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 3embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 4embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 5embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 6embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 7

FAQ





 embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 8embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 9embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 10

 embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 11




Packaging & Shipping

embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 12embedded 18.5" 19" inch open frame WIFI network android touchscreen TFT LED player AD signage display 13


Our Services

warranty: 12 months

Life-time maintenance.
