49" inch LED alone stand all-in-one touch PC kiosk interactive information terminal
table style 49 inch LCD all-in-one touchscreen PC table interactive game advertising display equipment
Product Description
Technical Parameter for LCD Panel:
Panel Size: 49 inch real color LCD screen Aspect Ratio: 16: 9
Active Area: 930.25mm(H) x 523.01mm(W)
49 inch Max. Resolution: 1920 x 1080 / 3840 x 2160
DOT Pitch: 0.227mm(H) x 0.227mm(W)
Panel Life: Above 50000 hours
49 inch Max. Brightness: 400CD/m2
Contrast Ratio: 5000: 1
Responsive Time: 3ms
Product Features and Technical Parameter:
- Color for outer shell: Silver Color for Aluminium Alloy and Black Color Main Outer shell; Also we accept customizing color according to color code.
- Adopts Samsung, LG (made in Korea) brand LCD Panel etc. Full new A+ grade and factory original packing screen.
- it is optional for support HDMI (1920 x 1080 / 3840 x 2160), DVD Player, S-video and VGA port.
- Safely locking system function to avoid take way Mini-PC.
- Build-in Mini-PC Support IR Touch Screen(2 dots) Function.
- Built-in two speakers stereo, rated power is 2 x 5W.
- Multi-language OSD: Chinese, English, Franch, Spanish, Korea etc.
- Power supply standard: AC 110V-240V 50/60Hz
Mini-PC Configuration Specifications:
- CPU: Intel Atom N270 1.6GHz or Intel® Atom Processor 330 (1M Cache, 1.6GHz, 533MHz FSB, Duel Core)
- Chipset: Intel 945GSE +ICH7 or NVIDIA ION Chipset
- RAM: 1GB DDR II RAM ( Up to 2GB) or 2GB DDR II 800 RAM (Up to 4GB)
- Graphics: Intel GMA950 graphics Controller or NVIDIA GeFore 9400M
- Audio: Raaltek ALC662 Audio Codec or HD 8-channel (7.1) audio subsystem
- Network Interface Card: Realtek 8111D Gigabit Ethernet Controller for 10/100/1000 Mbits/sec Ethernet LAN Connectivity.
- WiFi: 54M/300M Intel WiFi B/G/N WiFi technology support (optional) or High quality WiFi Module Included (802.11A/B/G)
- H. D. D: 2.5 INCH HDD or SSD Support ( Capacity support from 8G to 1.5T)
- O. D. D.: DVD-RW (Optional)
- Mouse/keyboard: Blutooth suit (Optional)
- Pre-installed OS: Windows XP/Vista/7 or Linux
Packing Information:
Packing list: 49 inch LCD advertising player, 6PCS keys, 1PCS English manual, 2PCS remote controller.
Packing size: 1940mm x 270mm x 900mm
Packing Material: Carton + Wooden case together
Net weight: About 96kg Gross weight: About 110kg
| Network system : | | | | |
| * Can be set split-screen 1to8 area for broadcasting video w/ photo, w/ other display of logo/ date/ weather/ roll-text or subtitles. |
| * Support format: JPG.PNG.BMP.AVI.MPG.MP4.WMV.MOV.MP3.WAV.TXT.GZ.IMG | |
| * Can set several assistant of administrator with limits of authority. | | |
| * Can set fixed time download, real-time download. And keep broadcasting when downloading. | |
| * Support terminal set password, for protect viciously control from outside. | | |
| * Support modify terminal IP by server software or by remote control. | | |
| * High definition, and support 1080P video. | | | |
| * Control one or all terminals. | | | | |
| * Support 3 roll-text. | | | | |
| * Support play files & roll-text in the specified time, support playlist. | | |
| * Support play video with connected photo and roll-text. | | | |
| * Can be set several clocks of power on and off. | | | |
| * Support cut-in broadcasting. | | | | |
| * Support vertical type. | | | | |
Applicable Field:
Business Organizations: Supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnshops;
Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Public Places: Subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers;
Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;
Entertainments: Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course.
warranty: 12 months
LIfe-time maintenance.
