Place of Origin:	Guangdong, China
Brand Name:	Shine Star/OEM
Certification:	CE-LVD, CE-EMC, FCC, ROHS, ISO9001
Model Number:	DS-S2-2

Minimum Order Quantity:	1 unit
Price:	To be negotiated
Packaging Details:	Depend on the final design you choose
Delivery Time:	15 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000 pieces per month

Application:	Indoor, Outdoor	Type:	LCD
Color:	Black, White, Silver	Supplier Type:	Original Manufacturer, ODM, Agency, Retailer, Other, OEM
Media Available:	Datasheet, Photo, EDA/CAD Models, Other	Use:	Advertising Publish, Retail Store, Shopping Mall, Display Of Dishes, Welcome Display, Self-service Business, Exhibition Hall, Wayfinding, Airport, Subway, Elevator, Restaurant & Hotel Supplies, Education, Medical Treatment
Specification:	Stretch Bar, Digital Poster, Touch Screen, Video Wall, Kiosk	Touch Screen Type:	Capacitive, Touchscreen, Infrared
Brightness:	350nits, 350nits	Display Ratio:	16:9, 16:9
Response Time:	2ms, 2ms	Contrast Ratio:	5000:1, 5000:1
Lifespan (hours):	100000, 100000	Installation Type:	Floor Standing, Floor Standing
HS Code:	8528591090	Resolution:	3840x2160
View Angle（H/V）:	178/178, 178/178	Optional Function 1:	Camera
Optional Function 2:	4G Network Function	Material:	Metal Case + Toughened Glass Panel
Optional Function 3:	Touch Screen Function	Optional Function 4:	RFID Reader
Built-in Speaker:	2*10W	Installation:	Floor Standing Kiosk
Input Voltage:	110V-240V	Operating System:	Standalone/Android/Win7/8/10/Linux
Optional Function:	3G/4G/Camera/Printer/Human Sensor/LOGO	Port:	All Of China Port
Highlight:	65 inch digital advertising kiosk , floor standing lcd advertising player 350nits , 65 inch floor standing lcd advertising player

*PRODUCT NAME	(1)BASIC PARAMETERS	Product Name	Double Side Digital Signage (S1)
		Product Model	DS-S1 43
* PRODUCT SPECIFICATION
CATEGORIES	CATEGORIES -2	DESCRIPTIONS
*PRODUCT SPECIFICATION	(1)LCD PARAMETERS	Screen Size	43 INCH
		Screen Type	LED industrial grade A standard LCD screen
		Screen Brand	LG
		Display Area	530MM*941MM
		Resolution	1920*1080
		Screen Ratio	16:09
		Brightness	350cd/㎡
		Contrast	1500:1
		Response Time	5.5ms
		Max. Color	16.7m
		Refresh Rate	5060hz
		Visual Angle	178°(H)178°(V)
		Service Lift	60000hours
	(2)HOST CONFIGURATION	Processor	Rockchip RK3288 maximum 64 -bit high -performance CPU, 2.0GHz;

		Chipset	1. Double Cortex-A72 large core+four Cortex-A53 small core 64-bit CPU2. Built-in low-power MCU Cortex-M0
		GPU	Quad-core ARM Mali-T860MP4 High-performance GPU
		Memory	2G (Optional)

		Storage	8G (Optional)


		Display function	LVDS output: 1 single/double road, you can directly drive 50/60Hz LCD screen

			EDP output: EDP interface LCD screen that can directly drive multiple resolution

		Network features	Wifi, BT: built -in WIFI, BT4.0 (optional) support dual -frequency WIFI

			3G: built -in WCDMA, EVDO, 4G full Netcom, support voice calls

			Ethernet: 2, which is 100M/1000M Ethernet, respectively

		Audio function	Audio and video output: Support left -right channel output, built -in dual 4R/20W, 8R/10W power amplifier


		Expansion port
		Back panel IO interface	TF card: support TF card
			HDMI output: 1, support 1080P@60Hz, 4kx2k@60Hz output
			HDMI in: hdmi input, 24Pin FPC custom interface
			USB interface: a Type C, 1 USB3.0, 1 USB2.0 Host, 3 USB sockets

		Operating system	Android 7.1
	(3)CABINET PARAMETERS	Cabinet Material	Tempered explosion-proof glass, Aluminum alloy frame, Iron sheet metal body

		Cabinet Color	TransparentCustomizable
* EQUIPMENT SPECIFICATION
CATEGORIES	CATEGORIES -2	DESCRIPTIONS
*EQUIPMENT SPECIFICATION	(1)POWER PARAMETERS	Input Power	AC110-240V, 5060Hz
		Power Consumption	≤85W
		Standby Power Consumption	＜3W
	(2)WORKING ENVIRONMENT	Operating Temperature	0℃-38℃
		Working Humidity	10%-95%
		Storage Temperature	0℃-40℃
		Storage Humidity	10%-95%
	(3)ACCESSORIES	Bracket	1 PC
		Power Cable	1 PC
		Manual	1 PC
		Warranty Card	1 PC
		Certificate of Conformity	1 PC
	(4)PHYSICAL PARAMETERS	Screen Size	43"
		Net Weight	60KGS
		Gross Weight	80KGS
		Machine Dimension	709MM490MM1697MM
		Package(Carton) Dimension	910MM690MM1900MM
